31.80304.27
Hydraulic hinge EVO EV 835E11 N with integrated door closer, self-closing from an opening angle of 160°, aluminium, black anodized, Glass thickness 8 - 19 / 21.52 mm, glass/wall, DIN left
General
| Material | aluminium |
| Finish | black anodized |
| Mounting | glass/wall, DIN left |
| Glass thickness | 8 - 19 / 21.52 mm |
| Sales unit (SU) | unit |
| Carrying capacity | 120 kg/pair |
Description
can be installed on doors with frame profile, rebate depth 30 - 50 mm, with adjustable closing speed, with constant braking control, with 180° locking, min. door width 800 mm, max. door width 1200 mm, for temperatures from -15°C to + 40°C. The hinge has a pre-tension, therefore a closing stop is required
-
